X99-DELUXE II specifications summary
Storage
Intel
®
X99 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology 14 support
- 1 x SATA Express port (compatible with 2 x SATA 6.0 Gb/s ports)
- 8 x SATA 6.0 Gb/s ports*
- Supports Intel
®
Smart Response Technology**
* Due to chipset behavior, The SATA6G_78, SATA6G_910 ports do not support
IRST including RAID configuration.
** These functions will work depending on the CPU installed.
LAN
Gigabit Intel LAN connection- 802.3az Energy Efcient Ethernet (EEE)
appliance
Intel
®
I218-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Intel
®
I211-AT Gigabit LAN controller
ASUS LAN Guard
ASUS Turbo LAN Utility
Wireless Data
Network
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz
Up to 1300Mbps transfer speed
ASUS Wi-Fi GO! Utility
Bluetooth
Bluetooth v4.0
Audio
Realtek
®
ALC1150 8-channel high denition audio CODEC featuring Crystal
Sound 3
- Power pre-regulator reduces power input noise to ensure consistent
performance
- Absolute Pitch 192khz/24bit true BD lossless sound
- Audio Amplier to enhance the highest quality sound for headphone and
speakers
- Audio shielding ensures precision analog/digital separation and greatly
reduced multi-lateral interference
- BD audio layer content protection
- DTS Connect
- DTS Studio Sound
- High quality 112dB SNR stereo playback output (Line-out@back) & 104dB
SNR recording input (Line-in) support
- Optical S/PDIF out port at back I/O
- Premium Japan-made audio capacitors provides warm, natural, and
immersive sound with exceptional clarity and delity
- Separate layer for left and right track, ensuring both sound deliver equal
quality
- Supports jack-detection, multi-streaming, front panel jack-retasking (MIC)
- Top notch audio sensation delivers according to the audio conguration
- Unique de-pop circuit to reduce start-up popping noise to audio outputs
