Asus x99-deluxe ii [14/128] X99 deluxe ii specifications summary

xiv

X99-DELUXE II specifications summary

Rear Panel I/O

Ports

1 x BIOS Flashback button

1 x ASUS 3T3R Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth

v4.0)

1 x Optical S/PDIF out

2 x Intel LAN (RJ45) ports

3 x USB 3.1/3.0/2.0 ports (teal blue, Type-A)

1 x USB 3.1/3.0/2.0 port (Type-C)

4 x USB 3.0/2.0 ports (blue)

4 x USB 2.0/1.1 ports (black)

8-channel Audio I/O ports

Internal I/O

connectors

2 x USB 3.0/2.0 connectors support additional 4 USB ports (19-pin)

2 x USB 2.0/1/1 connectors support additional 4 USB ports

1 x M.2 PCIe 3.0 x4 Socket 3 with vertical M Key design, type

2242/2260/2280 (Support PCIe storage device only)

1 x SATA Express connector

8 x SATA 6.0Gb/s connectors

1 x CPU Fan connector

1 x CPU OPT Fan connector

1 x High AMP Fan header

1 x Water Pump header

2 x Chassis Fan connectors

1 x RGB header

1 x Front panel audio connector (AAFP)

1 x S/PDIF out header

1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX 3 support

1 x TPM connector

1 x 24-pin EATX Power connector

1 x 8-pin EATX 12V Power connector

1 x 4-pin EATX 12V Power connector

1 x System Panel(Q-Connector)

1 x 5-pin EXT_FAN(Extension Fan) connector

1 x 2-pin Thermal sensor header

1 x 3-pin CPU OverVoltage(OV) header

1 x MemOK! button

1 x Clear CMOS button

1 x DRCT(Direct Key) connector

1 x EZ XMP switch

1 x SLI/CFX switch (2/3-WAY adjustments)

1 x Power-on button

1 x Reset button

(continued on the next page)
