ASUS X99-A II

3-23

Chapter 3

3.6.4 System Agent Conguration

3.6.5 USB Conguration

The items in this menu allow you to change the USB-related features.

The Mass Storage Devices item shows the auto-detected values. If no USB device is

detected, the item shows None.

USB Single Port Control

This item allows you to enable or disable the individual USB ports.

Refer to section 1.1.2 Motherboard layout for the location of the USB ports.
