Cisco 300 Series Managed Switches 9

NOTE Details on how to change the IP address on your computer

depend upon the type of architecture and operating system you are

using. Use the computer Help and Support functionality to search for “IP

Addressing.”

STEP 3 Open a Web browser window. If you are prompted to install an

Active-X plug-in when connecting to the device, follow the

prompts to accept the plug-in.

STEP 4 Enter the switch IP address in the address bar and press Enter. For

example, http://192.168.1.254.

The Switch Login Page displays.

STEP 5 Enter the default login information:

• Username is cisco

• Default password is cisco (passwords are case sensitive)

STEP 6 If this is the first time that you have logged on with the default

username and password, the Change Password page opens. The

rules for constructing a new login and password are displayed on

the page. Enter a new administrator password and click Apply.

CAUTION Make sure that any configuration changes made are saved to

the Startup configuration before exiting from the web-based

interface by clicking on the Save icon. Exiting before you

save your configuration will result in all current changes

being lost the next time the switch is rebooted.

The Getting Started window displays. You are now ready to configure the

switch. Refer to the Cisco 300 Series Managed Switch Administration

Guide for further information.

Use the console port

To configure the switch by using the console port:

STEP 1 Connect a computer to the switch console port using the provided

serial cable.

STEP 2 Start a terminal application such as HyperTerminal on the

computer.

STEP 3 Configure the utility with the following parameters:

• 115200 bits per second (with release 1.2.5 of the firmware,

autobaud detection is enabled by default, so the switch should

detect the speed after you press Enter).
