ACTIVE WEDGE

SPECIFICATIONS

 CP-AW1120 CP-AW2120

PeakPower(Watts) 750 900

RatedPower(Watts) 250 300

FrequencyResponse 32Hz-250Hz 32Hz-250Hz

LowPassFilter(Variable) 40Hz-250Hz 40Hz-250Hz

Tuning BassReex BassReex

WooferSize 12” Dual12”

LEVEL

Thisallowstheadjustmentoftheamplierlevelofthesubwoofer.

Turnclockwisetoincreasethelevel.Ifthesoundbecomesdistorted

reducethelevel.

LOW PASS FILTER (LPF)

This allows the adjustment of the highest frequency the Active

Wedgewillproduce.Thisshouldbeadjustedtoblendwithyourmain

speakers.Typically,thiswillbesettoaround100Hz(approximately

thecentralpositionofthecontrolknob).

REMOTE LEVEL CONTROLLER

DO NOT mount the Active Wedge in such a way as to pinch or

damagethewires.

Make sure everything is rmly connected, before attaching the

+12Vwire.Ensurethe+12Vwireisfusedascloseaspossibletothe

battery.Alwaysuseafusewiththerecommendedrating.

DISCLAIMER

AlwaysensuretheActiveWedgeissecurelyattached,toavoidmovement.FUSIONacceptsnoresponsibilityfordamageorinjuryinrelation

toinappropriatesecuringofthisproduct.

• Connectthegroundwiretothevehiclerst(cleandirtandpaint

 tobaremetal).

• Checkallconnections.
