HansGrohe 31806000 focus e2 [4/36] Assembly see page 31

Assembly see page 31

Test certificate (see page 36)

Cleaning

see enclosed brochure.

Operation (see page 34)

Hansgrohe recommends not to use as

drinking water the first half liter of water

drawn in the morning or after a prolonged

period of non-use.

Spare parts (see page 35)

Flow diagram

(see page 33)

Dimensions (see page 33)

Adjustment

To adjust the hot water limiter on single lever

mixers, please see page 32. No adjustment

is necessary when using a continuous flow

water heater.

Do not use silicone containing acetic acid!

Symbol description

6 Safety Notes

6 Gloves should be worn during installation to prevent

crushing and cutting injuries.

6 The hot and cold supplies must be of equal

pressures.

Installation Instructions

• Prior to installation, inspect the product for transport

damages. After it has been installed, no transport or

surface damage will be honoured.

• The fitting must be installed, flushed and tested after

the valid norms.

Technical Data

Operating pressure: max. 1 MPa

Recommended operating pressure: 0,1 – 0,5 MPa

Test pressure: 1,6 MPa

(1 MPa = 10 bar = 147 PSI)

Hot water temperature: max. 80°C

Recommended hot water temp.: 65°C

Hansgrohe mixers can be used together with

hydraulically and thermically controlled continuous flow

heaters if the flow pressure is at least 0,15 MPa.

The product is exclusively designed for drinking water!

English
