Size and weight specifications
The S2 42U standard rack and S2 42U expansion rack conform to the Electronic
Industries Association (EIA) standard EIA-310-D Cabinets, Racks, Panels, and
Associated Equipment (1992). For the rack cabinet dimensions and weights, see
Table 1 and Table 2.
Table 1. IBM S2 42U Dynamic Standard Rack and IBM S2 42U Dynamic Expansion Rack
physical dimensions
Configuration Dimensions
S2 42U dynamic standard rack cabinet
without outriggers
2000 mm x 605 mm x 1000 mm (78.7 in. x
23.8 in. x 39.4 in.)
S2 42U dynamic standard rack cabinet
with outriggers
2000 mm x 725 mm x 1000 mm (78.7 in. x
28.5 in. x 39.4 in.)
S2 42U dynamic expansion rack cabinet
without outriggers
2000 mm x 600 mm x 1000 mm (78.7 in. x
23.6 in. x 39.4 in.)
S2 42U dynamic expansion rack cabinet
with outriggers
2000 mm x 725 mm x 1000 mm (78.7 in. x
28.5 in. x 39.4 in.)
Table 2. IBM S2 42U Dynamic Standard Rack and IBM S2 42U Dynamic Expansion Rack
weights
S2 42U dynamic standard rack S2 42U dynamic expansion rack
Empty (with
outriggers)
142 kg (313 lb) 111 kg (245 lb)
Total load 950 kg (2094 lb) 950 kg (2094 lb)
Maximum
configuration
1092 kg (2407 lb) 1061 kg (2339 lb)
Chapter 2. Installing a rack cabinet 7
