DANGER

Overloading a branch circuit is potentially a fire hazard and a shock hazard

under certain conditions. To avoid these hazards, ensure that your system

electrical requirements do not exceed branch circuit protection

requirements. Refer to the information that is provided with your device for

electrical specifications.

xiv IBM System x3250 M4 Type 2583: Installation and User’s Guide
