![IBM x3250 m4, 2583kcg [24/102] Table 1 features and specifications continued](/img/pdf.png)
IBM x3250 m4, 2583kcg [24/102] Table 1 features and specifications continued
![IBM x3250 m4, 2583kcg [24/102] Table 1 features and specifications continued](/views2/1219896/page24/bg18.png)
Table 1. Features and specifications (continued)
RAID controllers (depending on the
model):
v Software RAID capabilities that support
RAID levels 0, 1, and 10
v ServeRAID-BR10il v2 SAS/SATA
adapter that provides RAID levels 0, 1,
and 10
Acoustical noise emissions:
v Sound power, idling: 6.5 bels maximum
v Sound power, operating: 6.5 bels
maximum
Environment:
v Air temperature:
– Server on: 10°C to 35°C (50.0°F to
95.0°F); altitude: 0 to 914.4 m (3000
ft)
– Server on: 10°C to 32°C (50.0°F to
89.6°F); altitude: 914.4 m (3000 ft) to
2133.6 m (7000 ft)
– Server on: 10°C to 28°C (50.0°F to
83°F); altitude: 2133.6 m (7000 ft) to
3050 m (10000 ft)
– Server off: 10°C to 43°C
(50°F to 109.4°F); maximum altitude:
2133.6 m (7000.0 ft)
– Shipping: -40°C to 60°C
(-104°F to 140°F)
v Humidity:
– Server on: 8% to 80%
– Serveroff:8%to80%
v Particulate contamination:
Attention: Airborne particulates and
reactive gases acting alone or in
combination with other environmental
factors such as humidity or temperature
might pose a risk to the server. For
information about the limits for
particulates and gases, see “Particulate
contamination” on page 73.
Video controller (integrated into IMM2):
v Matrox G200
v SVGA compatible video controller
v Avocent Digital Video Compression
v Video memory is not expandable
Note: Maximum video resolution is 1600 x
1200 at 75 Hz.
Size:
v 1U
v Height: 43 mm (1.69 inches)
v Depth: 575.8 mm (22.67 inches)
v Width:
– 439 mm (17.28 inches) (without rack
brackets)
– 478 mm (18.82 inches) (with rack
brackets)
v Maximum weight: 10.67 kg (23.53 lb)
depending on your configuration
Heat output:
Approximate heat output:
v Minimum configuration: 150 BTU per
hour (44 watts)
v Maximum configuration: 1421 BTU per
hour (416 watts)
Electrical input:
v Sine-wave input (50 / 60 Hz) required
v Input voltage low range:
– Minimum: 100 V ac
– Maximum: 127 V ac
v Input voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
v Input kilovolt-amperes (kVA),
approximately:
– Minimum: 0.044 kVA
– Maximum: 0.416 kVA
Notes:
1. Power consumption and heat output
vary depending on the number and
type of optional features installed and
the power-management optional
features in use.
2. The sound levels were measured in
controlled acoustical environments
according to the procedures specified
by the American National Standards
Institute (ANSI) S12.10 and ISO 7779
and are reported in accordance with
ISO 9296. Actual sound-pressure levels
in a given location might exceed the
average values stated because of room
reflections and other nearby noise
sources. The noise emission level
stated in the declared (upper limit)
sound-power level, in bels, for a
random sample of system.
3. There is no keyboard connector or
mouse connector on the server. You
can connect a USB keyboard and USB
mouse to the server by using the USB
connectors.
6 IBM System x3250 M4 Type 2583: Installation and User’s Guide
