ENGLISH
APPENDIX 27
SPECIFICATIONS
APPENDIX
Design and specifi cations are subject to change without prior notice.
LCD Panel
Panel technology
TN
0.16mm H × 0.16mm V
Response time
Pixel pitch
5ms (Typical), 1ms (Gray to Gray)
Display Colors
Approx. 1.07 Billion
Sync Frequency VGA: Horizontal: 30.0-80.0kHz, Vertical: 55-75Hz
HDMI1: Horizontal: 30.0-135.0kHz, Vertical: 24-30,55-75Hz
HDMI2/MHL: Horizontal: 30.0-90.0kHz, Vertical: 24-30,55-75Hz
HDMI3: Horizontal: 30.0-90.0kHz, Vertical: 24-30,55-75Hz
DisplayPort
(without FreeSync)
:
Horizontal: 30.0-135.0kHz, Vertical: 24-30,55-75Hz
DisplayPort
(with FreeSync)
:
Horizontal: 30.0-135.0kHz, Vertical: 35-60Hz
Native Resolution 3840 × 2160, 8.3 MegaPixels
Input Connector
VGA(D-sub) mini 15 pin, HDMI x3, DisplayPort
Plug & Play
VESA DDC2B
TM
42W typical, Power management mode: 0.5W maximum
Energy Effi ciency Class: B
Power Consumption*
2
Dimensions / Net Weight
663.0 × 413.5 - 543.5 × 230.0mm / 26.1 × 16.3 - 21.4 × 9.1" (W×H×D)
7.7kg / 16.9lbs
Viewable angle Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical)
Maximum Screen Size
620.9mm W × 341.3mm H / 24.4" W × 13.4" H
Power Source
100-240VAC, 50/60Hz, 1.0A
Brightness
Contrast ratio
300cd/m
2
(Typical)
1000 : 1 (Typical), Adv. Contrast Function Available
Analog: 0.7Vp-p (Standard), 75
Positive
Digital: HDMI, HDMI (MHL compliance)*
1
, DisplayPort
Input Video Signal
Input Audio Signal 1.0Vrms maximum
Speakers
3W × 2 (Stereo speakers)
Input Audio Connector ø 3.5mm mini jack (Stereo)
Size Category 28"
Diagonal: 28" (71cm)Size
Headphone Connector ø 3.5mm mini jack (Stereo)
USB Standard USB3.0
Number of USB Ports
Connector shape
1 Upstream : Series B
2 Downstream : Series A
Input Sync Signal Separate sync: TTL, Positive or Negative
Supported max. resolution
VGA : 2048 × 1152 60Hz
HDMI1 : 3840 × 2160 60Hz
HDMI2/MHL: 3840 × 2160 30Hz, 2560 × 1440 60Hz,
1920 × 2160 60Hz(HDMI),
1920 × 1080 60Hz(MHL)
HDMI3: 3840 × 2160 30Hz, 2560 × 1440 60Hz, 1920 × 2160 60Hz
DisplayPort:
3840 × 2160 60Hz
