ii
Warning
Read all caution and safety
statements in this document
before performing any of the
instructions. Also see the Intel
®
Server Board and Server Chassis
Safety Information document at:
http://www.intel.com/support/
motherboards/server/sb/cs-010770
.htm for complete safety information.
Warning
Installation and service
of this product to be
performed only by
qualified service personnel
to avoid risk of injury from
electrical shock or energy
hazard.
Caution
Observe normal ESD
[Electrostatic Discharge]
procedures during system
integration to avoid possible
damage to server board and/or
other components.
Tools Required
Anti-static
wrist strap
Phillips*
screwdriver
Intel is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the
property of others. Copyright © 2012, Intel Corporation. All rights reserved.
Thermal Operation and Configuration Requirements
To keep the system operating within supported maximum thermal limits, the system must meet the following operating and
configuration guidelines:
• Ambient inlet temperature cannot exceed 35º C and should not remain at this maximum level for long periods of time.
Doing so may affect long term reliability of the system.
• The CPU-1 processor + CPU heatsink must be installed first. The CPU-2 heatsink must be installed at all times,
with or without a processor installed.
• Memory Slot population requirements:
NOTE: Specified memory slots can be populated with a DIMM or supplied DIMM Blank. Memory population rules
apply when installing DIMMs.
– DIMM Population Rules on CPU-1
Install DIMMs in order; Channels A, B, C, and D. Start with 1
st
DIMM slot (blue) on each channel, then slot 2,
then slot 3 (24 DIMM board). Only remove DIMM blanks when populating the slot with a DIMM.
– DIMM Population on CPU-2
Install DIMMs in order; Channels E, F, G, and H. Start with 1
st
DIMM slot (blue) on each channel, then slot 2,
then slot 3 (24 DIMM board). Only remove DIMM blanks when populating the slot with a DIMM.
The following system configurations require the specific memory slots be populated at all times using a DIMM or supplied
DIMM blank:
– System Configuration: 24x 2.5" hard drive bay or 12x 3.5" hard drive bay configuration + 24 DIMM server
board Memory slots 2 and 3 populated on all memory channels.
– System Configuration: 16x 2.5" hard drive bay or 8x 3.5" hard drive bay configuration + 24 DIMM server board
Memory slot 3 populated on all memory channels.
– System Configuration: 24x 2.5" hard drive bay or 12x 3.5" hard drive bay configuration + 16 DIMM server board
Memory slot 2 populated on all memory channels.
• All hard drive bays must be populated. Hard drive carriers either can be populated with a hard drive or supplied
drive blank.
• The air duct must be installed at all times.
• In single power supply configurations, the second power supply bay must have the supplied filler blank installed at
all times.
• The system top-cover must be installed at all times. The only exception to this requirement is to hot replace a failed
system fan, in which case the top cover can be removed for no more than three minutes at a time.
