Lenovo b5130, 80lk00klrk [46/52] To replace the optical drive do the following

Appendix A. CRU instructions

Replacing the optical drive - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

To replace the optical drive, do the following:

Remove the battery pack. For details, see “Replacing the battery pack” on

page 33.

Remove the screw .

B41-35/B41-30/N41-35/N41-30:

B51-35/B51-30/N51-35/N51-30:

Note:

• Make sure the computer is turned off and all the cables disconnected from the computer

before you replace the optical drive.

• Make sure the computer display is closed to avoid being damaged.
