Chapter 1. Getting to know your computer

 B51-35/B51-30/N51-35/N51-30

Note:

• The dashed areas indicate parts that are invisible from the outside.

• The illustrations may differ from the actual product. Please refer to the actual product.

Attention:

• Do not open the display panel beyond 130 degrees. When closing the display panel,

be careful not to leave pens or any other objects in between the display panel and the

keyboard. Otherwise, the display panel can be damaged.
