Energenie UPS-PS-003 [3/12] Specifications for ups ps 002

UPS-PS-001, UPS-PS-002, UPS-PS-003

PURE SINE WAVE UPS

All brands and logos are registered trademarks of their respective owners

Specifications for UPS-PS-001

 Type: line interactive

 Waveform: sine, 5% distortion at linear load, PF > 0.6

 Input: AC 220V ± 25%, 50 Hz / 60 Hz ± 10%

 Output: AC 220V ± 12%, 50 Hz / 60 Hz ± 1% (AC 220V ± 5% at inverter mode)

 Switching time: 5 ms typically (8 ms max)

 Backup time: 10...30 mins (depends on the load)

 Battery: sealed lead-acid 12V / 7Ah x 2 pcs

 Charge time: up to 12 hours

 Sockets: Schuko EU type, 1 input, 3 outputs; USB-BF connector

 Operating conditions: 0°C ~ 40°C, at humidity 10 ~ 90% RH non condensing

 Power: 1000 VA (600 W)

 Charging current: up to 1.2 A

 Noise: < 50 dB at 1 m distance

 Dimensions: 360 x 215 x 145 mm

 Product weight: 14.5 kg

Specifications for UPS-PS-002

 Type: line interactive

 Waveform: sine, 5% distortion at linear load, PF > 0.6

 Input: AC 220V±25%, 50Hz/60Hz ±10%

 Output: AC 220V±12%, 50Hz/60Hz ±1% (AC 220V±5% at inverter mode)

 Switching time: 5 ms typically (8 ms max)

 Backup time: 10...30mins (depends on the load)

 Battery: 151 x 65 x 95 mm, sealed lead-acid 12V/8Ah x 3 pcs

 Charge time: up to 12 hours
