Energenie UPS-PS-003 [4/12] Specifications for ups ps 003

UPS-PS-001, UPS-PS-002, UPS-PS-003

PURE SINE WAVE UPS

All brands and logos are registered trademarks of their respective owners

 Sockets: C14 input, 4 outputs x C13; USB-BF connector

 Operating conditions: 0°C~40°C, at humidity 10~90%RH non condensing

 Power: 2000VA (1200 W)

 Charging current: up to 1.2 A

 Noise: < 50 dB at 1 m distance

 Dimensions: 430 x 215 x 145 mm

 Product weight: 18.5 kg

Specifications for UPS-PS-003

 Type: line interactive

 Waveform: sine, 5% distortion at linear load, PF > 0.6

 Input: AC 220V±25%, 50Hz/60Hz ±10%

 Output: AC 220V±12%, 50Hz/60Hz ±1% (AC 220V±5% at inverter mode)

 Switching time: 5 ms typically (8 ms max)

 Backup time: 10...30 mins (depends on the load)

 Battery: 151 x 65 x 95 mm, sealed lead-acid 12V/8Ah x 4 pcs

 Charge time: up to 12 hours

 Sockets: C14 input, 4 outputs x C13; USB-BF connector

 Operating conditions: 0°C~40°C, at humidity 10~90%RH non condensing

 Power: 3000VA (1800 W)

 Charging current: up to 1.2 A

 Noise: < 50 dB at 1 m distance

 Dimensions: 475 x 337 x 190 mm

 Product weight: 27 kg
