2 Installation

This chapter describes how to install and configure the QLogic Host Bus Adapter

in three simple steps:

 Step 1. Install the Hardware

 Step 2. Install the Adapter Driver

 Step 3. Install QConvergeConsole

Step 1. Install the Hardware

To install the adapter hardware, you need to open the computer and locate the

appropriate bus slot. If necessary, consult your computer system manual for

instructions to remove the computer cover.

Installing the QLA2xx, QLA23xx, QLA24xx, QLE2xx, QLE236x,

QLE24xx, and QLE25xx Adapters

To install the adapter hardware:

1. Power off the computer and all attached devices such as monitors, printers,

and external components.

2. Disconnect the power cable.

3. Remove the computer cover and find an appropriate empty bus slot.

CAUTION

Keep the adapter in the antistatic bag until installation. The Host Bus

Adapter contains parts that can be damaged by electrostatic discharge

(ESD). Before handling the Host Bus Adapter, use standard methods to

discharge static electricity. Place the Host Bus Adapter on the bag when

examining it. Retain the bag for future use.

NOTE

The QOE2562 installation procedure differs from these adapter models; see

“Installing the QOE2562 Adapter” on page 8
