29Chapter 3: Inspecon and Adjustment
FIGURE 3.28
Wheel aachment types:
1. Tradional quick-release
2. Nued axle
3. Threaded skewer (with hex
wrench)
4. OCC thru-axle
5. DT RWS thru- axle
1
2
3
4
5
WARNING: A quick-release or
other wheel attachment device that
is not correctly adjusted and closed
can cause the wheel to be loose or
come off, suddenly stop the wheel,
decrease your control, and cause
you to fall. Make sure the wheels
are correctly attached before you
ride your bicycle.
Types of wheel aachment devices
See these devices in Figure 3.28:
• Tradional quick-release
• Threaded axle and nut
• Threaded skewer and nut
(hex wrench type)
• OCC (Over-Center Cam) thru-axle
• DT RWS thru-axle
• Make sure a locked quick-release lever can
not be turned (Figure 3.30).
• When a quick-release is correctly locked, the
clamp-force is sucient to cause metal-
into-metal engagement (embossing) of the
dropout surfaces.
• For more informaon about the correct
opening and closing forces on an OCC lever,
read the Actual Measurements.
Test the wheel aachment
For the device(s) on your bike, follow the
instrucons to make sure your wheels are
correctly aached. If the aachment does not
pass a test, aach the wheel again or take
your bicycle to your retailer for service. Do
the tests again before each ride.
• Li your bicycle and hit the top of the re
with a solid blow (Figure 3.29). The wheel
should not come o, be loose, or move
from side to side.
• For a nued axle or threaded skewer, make
sure the device it ghtened to the correct
torque specicaon.
• For a quick-release lever, make sure the
resistance is correct as you move the lever
to the CLOSE posion.
FIGURE 3.29
Test for loose condion
FIGURE 3.30
Make sure the lever does
not turn
Actual Measurements for an OCC (Over-
Center Cam) Lever
If more than 45 pounds (200 Newton) force
is necessary to lock the lever, slightly loosen
the adjustment-nut. If less than 12 pounds
(53.4 Newton) force is necessary to release
the lever, slightly ghten the adjustment-nut.
