– 1 –
GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
DLP PROJECTOR WITH LENS CAP
REMOTE CONTROL
(WITH TWO AAA
BATTERIES)
RGB CABLE
POWER CORD
HDMI CABLE
CARRYING CASE
CD-ROM
(THIS USER’S MANUAL)
QUICK START GUIDE
WARRANTY CARD
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It
is recommend that you keep the original packing material should you ever need to return the equipment
for warranty service.
