Access CWIS

Xerox WorkCentre 4250/4260 Series System Administration Guide 161

2. In the URL field, enter http:// followed by the IP Address of the machine. For

example: If the IP Address is 192.168.100.100, enter the following into the URL field:

192.168.100.100.

3. Press [Enter] to view the Home page.

4. Click a tab to access the desired page, or click on the Index icon at the top of the

machine web page to access the index and contents list.

Network Factory Default button

This button can be found on the [Status] tab and is used to reset Network parameters to

factory default values from the Internet. It causes the machine to set all Network values

back to factory default. This will cause an Immediate Image Overwrite of any incomplete

print or network scan jobs being processed when the Network Controller is rebooted.

Once the button is selected, the following will occur:

1. If the System Administrator is already authenticated as an administrator the

machine will reboot. The web-browser will not be able to connect to the machine via

the Web UI until the network controller has reset.

2. If the System Administrator is not already authenticated, the Administration

Authentication screen will appear so authentication can be performed. Once this has

successfully occurred, the Administration Authentication screen will close and the

machine will reboot. The web browser will not be able to connect to the machine via

the CWIS until the Network Controller has been reset.

General

The General page allows you to view the Name, Location, IP Address and Status of the

machine.

1. At your Workstation, open the web browser, enter the TCP.IP Address of the machine

in the Address bar.

2. Press [Enter].

3. Click on the [Status] tab.

4. Click on the [General] link.

Rebooting the machine

It is possible to reboot the machine from CentreWare Internet Services by clicking on

[Reboot Machine]. The Network Controller takes approximately 5 minutes to reboot and

network connectivity will be unavailable during this time.

Alerts

The Alerts page allows you to view all current alert messages. Each alert will specify what the

problem is and a solution to the problem.

1. At your Workstation, open the web browser, enter the TCP/IP Address of the machine

in the Address bar.
