Condtrol neo g200 [5/27] Condtrol neo g200 condtrol neo g200

8 9

user manual

CROSS

LINE LASER

user manual

CROSS

LINE LASER

CONDTROL NEO G200 CONDTROL NEO G200

TECHNICAL SPECIFICATIONS

Working range 50 m

Self-leveling accuracy ±0,3 mm/m

Self-leveling range ± 4,5°

Continuous working time 15 hours

Operating temperature 0°C ... +50°C

Storage temperature -20°C ... +70°C

Tripod mounting thread 5/8’’, 1/4’’

Laser type Class II 532 nm < 1 mW

Power supply 3 х 1.5V LR6 alkaline (AA)

Dimensions 120х75х105mm

Weight 0,5 kg

SET

NEO G200

Laser level NEO G200, magnetic holder, adapter 5/8’’ – 1/4’’, cable tie,

pouch, batteries 3 pcs (AA), user manual.

OPERATION

Before start operation remove the battery cover, insert the batteries,

observing correct polarity. Put battery cover back.

Use alkaline AA batteries only, all batteries should be of the same type

and brand with the same charge level. Replace batteries if battery

charge level indicator turns red while operation.

Place an instrument on a firm and stable surface or a tripod.

Move compensator lock to choose necessary operating mode:

1) Automatic leveling, to build horizontal and vertical planes and

lines:

Move lever lock to unlocked position . Compensator is unlocked.

If the product is out of the range of automatic compensation it will

emit sound signal.

Short press button to turn on necessary laser planes.

Short press button to turn on/off pulse mode that allows

working with laser receiver. In this mode pulse mode indicator will

turn green.

To switch off the product move lever lock to locked position .

1) Locked compensator, to build inclined planes and lines:

Move lever lock to locked position . Compensator is locked. Short

press button to turn on the product. Horizontal plane will

switch on. Locked pendulum indicator turns red.

Short press button to turn on necessary laser planes.
