Xoro HXS 532 [8/60] Amplifier input parameters

Xoro HXS 532 [8/60] Amplifier input parameters
7
FUNCTION OVERVIEW
FEATURES
l
l
l
l
l
l
1 W total output power (RMS )
Connection stereo source (i.e. CD player)
ull function remote control
Integrated 5.1 channel amplifier
80 atts , THD 10%
Connection to DVD player with 5.1 channel analog output
to
F
High manufacturing quality
SPECIFICATIONS
l General Information
Type ........5.1Channels Active Sound System
Power Input ..............220VAC~50/60 Hz
Power Consumption ................. 180W
Gross Weight.......................34,8 kgs
Dimension (L x W x H) ......652x465x490mm
£
l Amplifier Input Parameters
Analog Inputs............5.1and2.0line inputs
Max. Input Voltage:
Stereo Line Input (AUX IN).............350mV
5.1 Input (DVD IN) Front/Surr./Center ....300mV
5.1 Input (DVD IN) Subwoofer ..........220mV
l Amplifier Output Parameters
Total Power (RMS): THD 1%.......145W
THD10% .....180W
Front Channels (RMS, measured at 1 kHz):
THD1%.....2x14W
THD10%....2x20W
Surround Channels (RMS, measured at 1 kHz):
THD1%.....2x14W
THD10%....2x20W
Center Channel (RMS, measured at 1 kHz):
THD1%.....2x14W
THD10%....2x20W
Subwoofer Channel (RMS, measured at 100 Hz):
THD1%.....1x75W
THD10%....1x80W
Signal to Noise Ratio ................. 70dB
THD(1W)...........................<1%
³
l Amplifier Terminals
5.1 Input ...........Analog 5.1 Line Input (RCA)
2.0 Input ........Analog Stereo Line Input (RCA)
Output ............5.0Amplified Output (Spring)
Fuse Socket
Power Switch
Power Cord Input
l Front Channels Speakers
2-way vented MDF enclosure loudspeakers
Frequency Response ...........90Hz~20kHz
Speaker Impedance (nominal) ...........4Ohm
Power Handling.................10~45Watts
Dimensions (W x H x D) .....150x260x167mm
Net Weight .......................2x2,5kgs
Woofer ...................1xPaper cone (4")
Tweeter .....................1xMylar (0.75")
l Surround Channels Speakers
2-way closed MDF enclosure loudspeakers
Woofer ...................1xPaper cone (4")
Tweeter .....................1xMylar (0.75")
Frequency Response ..........100Hz~20kHz
Dimensions (W x H x D) .....150x260x167mm
Net Weight .......................2x2,7kgs
Speaker Impedance (nominal) ...........4Ohm
Power Handling.................10~45Watts
l Center Channel Speaker
2-way vented MDF enclosure loudspeaker
Woofer ...................2xPaper cone (4")
Tweeter .....................1xMylar (0.75")
Frequency Response ...........90Hz~20kHz
Dimensions (W x H x D) .....390x150x167mm
Net Weight .......................1x3,7kgs
Speaker Impedance (nominal) ...........4Ohm
Power Handling.................10~50Watts
l Subwoofer Channel Speaker
Vented MDF enclosure loudspeaker
Woofer ...................1xPaper cone (8")
Frequency Response ...........35Hz~100Hz
Dimensions (W x H x D) .....230x402x442mm
Net Weight ......................1x14,1 kgs
Speaker Impedance (nominal) ...........4Ohm
