PA3500/4200
22
Output charts water PA3500
PA3500 WHH*
Special coil Incoming / outgoing water temperature 130/70 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WHH* max 1800 15,7 41 0,07 3,8 14,5 44 0,06 3,3
min 860 10,0 49 0,04 1,7 9,2 52 0,04 1,5
PA3515WHH* max 2600 23,5 41 0,10 2,0 21,6 45 0,09 1,7
min 1240 14,8 50 0,06 0,9 13,6 53 0,06 0,8
PA3520WHH* max 3200 31,2 43 0,13 4,1 28,8 47 0,12 3,5
min 1530 19,6 52 0,08 1,8 18,1 55 0,07 1,5
PA3525WHH* max 4600 42,3 42 0,17 2,8 39,1 45 0,16 2,4
min 2200 26,7 50 0,11 1,2 24,6 53 0,10 1,1
*) Air curtain equipped with water coil WHH is available on request.
PA3500 WH
Standard coil Incoming / outgoing water temperature 110/80 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WH max 1800 16,0 41 0,13 11,0 14,8 44 0,12 9,6
min 860 10,1 49 0,08 4,8 9,4 52 0,08 4,2
PA3515WH max 2600 24,1 42 0,20 6,1 22,3 45 0,18 5,3
min 1240 15,1 51 0,12 2,6 14,0 53 0,12 2,3
PA3520WH max 3200 31,6 44 0,26 12,1 29,2 47 0,24 10,6
min 1530 19,7 53 0,16 5,2 18,2 55 0,15 4,5
PA3525WH max 4600 43,1 42 0,35 8,3 39,9 46 0,33 6,2
min 2200 27,1 51 0,22 3,6 25,0 54 0,21 3,1
PA3500 WH
Standard coil Incoming / outgoing water temperature 90/70 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WH max 1800 13,1 36 0,16 16,4 12,0 40 0,15 13,9
min 860 8,3 43 0,10 7, 2 7, 5 46 0,09 6,1
PA3515WH max 2600 19,7 37 0,24 9,2 18,0 41 0,22 7, 8
min 1240 12,4 44 0,15 3,9 11,3 47 0,14 3,3
PA3520WH max 3200 25,8 39 0,32 18,1 23,6 42 0,29 15,3
min 1530 16,1 46 0,20 7, 7 14,7 48 0,18 6,5
PA3525WH max 4600 35,3 37 0,43 16,8 32,2 41 0,39 14,2
min 2200 22,1 44 0,27 7, 1 20,2 47 0,25 6,0
PA3500 WH
Standard coil Incoming / outgoing water temperature 80/60 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WH max 1800 10,9 33 0,13 12,0 9,8 36 0,12 9,9
min 860 6,8 38 0,08 5,3 6,15 41 0,08 4,3
PA3515WH max 2600 16,4 33 0,20 6,7 14,6 37 0,18 5,4
min 1240 10,3 39 0,13 2,9 9,2 42 0,11 2,3
PA3520WH max 3200 21,5 35 0,26 13,3 19,3 38 0,24 10,9
min 1530 13,4 41 0,16 5,7 12,0 43 0,15 4,6
PA3525WH max 4600 29,3 34 0,36 12,1 26,2 37 0,32 9,9
min 2200 18,4 39 0,22 5,2 16,5 42 0,20 4,2
