Thermozone AG 4500/5000 A/W
22
GB
If there is no heat, check the following:
1. That there is hot water to the water
coil. (Check the circulation pump - if
applicable.)
2. That the heat demand exists; check
thermostat settings and actual temperature.
3. That the intake grille is not dirty.
If the fault cannot be rectified, please contact
a qualified service technician.
Safety
• Keeptheareasaroundtheairintake
andexhaustgrillesfreefrompossible
obstructions!
• Duringoperationthesurfacesoftheunit
are hot!
Technical data is on page 16.
