PA3500/4200
31
GB
Assembly and operating instructions
General Instructions
Read these instructions carefully before
installation and use. Keep this manual for
future reference.
The product may only be used as set out in
the assembly and operating instructions. The
guarantee is only valid if the product is used
in the manner intended and in accordance
with the instructions.
Application area
The Thermozone AR3500 air curtain unit
is supplied without heating, with electrical
heating or hot water heating
PA3500 is intended for entrances and
smaller doors up to 3.5 metres in height.
PA4200 is intended for larger door ways and
industrial door up to 4,2 metres in height.
Protection class for units with electrical
heating: IP20.
Protection class for units without heating and
units with water heating: IP21.
Operation
Air is drawn in at the top/rear of the unit and
blown out downwards/outwards so that it
shields the door opening and minimizes heat
loss. To achieve the optimum curtain effect
the unit must extend the full height/width of
the door opening.
The grille for directing exhaust air is
adjustable and is normally angled outwards to
achieve the best protection against incoming
cold air.
The efficiency of the air curtain depends
on the air temperature, pressure differences
across the doorway and any wind pressure.
NOTE! Negative pressure in the building
considerably reduces the efficiency of the air
curtain. The ventilation should therefore be
balanced.
Mounting
The air curtain range includes possiblities
for horizontal installation and for vertical
installation and the units can also be installed
recessed into suspended ceilings.
Horizontal mounting
The air curtain unit is installed horizontally
with the supply air grille facing downwards
as close to the door as possible. Minimum
distance from outlet to floor for electrically
heated units is 1800 mm. For other minimum
distances, see fig. 3.
For the protection of wider openings, several
units can be mounted next to each other
using a joining kit (fig. 8).
A design kit for a neat installation that
conceals cables, pipes and mountings
is available for both wall and ceiling
installations, se accessories pages.
Mounting with wall brackets PA34WB (fig. 5)
1. Remove the plastic covers on the wall
brackets. (Fig. 5A)
2. Mount the brackets on the wall according
to measures in fig. 5B.
3. Fasten the hammer head screws on the
unit in the holes M8. (Fig. 4 and 5C)
4. Lock the nuts so that the hammer head
screws are at 20 mm height. Note the
direction of the screw heads. (Fig. 5C)
5. Slide the unit on the consoles. (Fig. 5D)
6. Lock the nuts against the bracket and put
the plastic covers on again. (Fig. 5E)
Horizontal mounting on the ceiling
Threaded rods, wire suspension kits and
ceiling brackets for ceiling mounting are
available as accessories, see fig. 7 och 7 and
separate manuals.
Horizontal recessed mounting in false ceilings
Outlet extension used for recessed installation
is available as accessory, see fig. 9 and
separate manual.
