Hyundai h-hv1-10-ui562 [5/52] Attention

Electric convector

Overall and installation dimensions

H-HV2-10-

UI565

H-HV2-15-

UI566

H-HV2-20-

UI567

Nominal power consumption

W 1000 1500 2000

Nominal current А 4,5 6,8 9,1

Rated voltage V/Hz ~220/50 ~220/50 ~220/50

Protection class IP24 IP24 IP24

Electric protection class Class I Class I Class I

Weight Kg 5,4 6,6 7,6

Dimensions mm 613x88x450 770x88x450 890x88x450

H-HV3-10-

UI568

H-HV3-15-

UI569

H-HV3-20-

UI570

Nominal power consumption

W 1000 1500 2000

Nominal current А 4,5 6,8 9,1

Rated voltage V/Hz ~220/50 ~220/50 ~220/50

Protection class IP24 IP24 IP24

Electric protection class Class I Class I Class I

Weight Kg 7,2 9,8 10,2

Dimensions mm 613x95x450 770x95x450 890x95x450

            



ATTENTION!

The manufacturer reserves the right to change the set-list of the device



-

rameters of the device or may improve them, and also not violate the leg-

islation or quality standards of the countries of manufacture, transit and

selling. The changes in the set-list may result in changing of the weight

and dimensions of the device, but not more than by +\- 5-20% (depending

on the product category)

450

613 770 890

Fig. 2
