Hyundai h-hv1-10-ui562 [8/52] Connecting to the mains

Electric convector

WARNING!

The power outlet should be rated at least 10A for models with a

maximum capacity of up to 2000 W and at least 12 A for models with a

maximum capacity of 2500 watt.

6. OPERATION

For models:

H-HV1-10-UI562

H-HV1-15-UI563

H-HV1-20-UI564

5. CONNECTING TO THE MAINS

1. Convector is designed for connection to the plug with single-phase ~220 V, 50 Hz.



technical data of the device.

3. Convector when connected to the plug must comply with applicable electrical codes.

4. Electric outlet must be properly grounded. The receptacle must be rated for at least 10A.

Electrical plug and socket must always be kept dry to prevent electrical leakage. Regularly check





the power cord, check with the hand, whether the plug is not heated.



to poor electrical contact replace the socket with help of a specialist.

Floor installation

1. Carefully remove the heater from the package.

2. Make sure that the parts of the appliance have no remaining crumbles of packing foam plastic

or other debris.

3. Remove the two support legs from the packaging of the convector.

4. Turn the unit so that its bottom was in easy access.

                   



6. Tighten the screws in the existing holes.

Fig. 6

1000 W

300 494 600

118110119

1500 W 2000 W
