MAXIMUS IX EXTREME specifications summary

Back I/O Ports

1 x BIOS Flashback Button

1 x Clear CMOS button

1 x Wi-Fi module

1 x HDMI 1.4b

1 x DisplayPort 1.2

2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C [black])

6 x USB 3.0 ports [blue]

1 x Anti-surge LAN (RJ45) port

1 x Optical S/PDIF out

5 x Color-Coded LED audio jacks

Internal I/O Ports

1 x USB 3.0 headers support additional 2 USB 3.0 ports

2 x USB 2.0 headers support additional 4 USB 2.0 ports [one

connector via ROG_EXT header]

8 x SATA 6Gb/s ports

1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices

support (PCIE 3.0 x4 and SATA Modes)

1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage

devices support (PCIE 3.0 x4 and SATA Modes)

1 x ROG extension (ROG_EXT) header

2 x 4-Pin Chassis fan connectors

2 x 4-Pin Water_pump+ connector

1 x Thermal sensor connector

8 x 4 pin Radiator Fan connectors

1 x 24-pin EATX power connector

1 x 8-pin EATX 12V power connector

1 x 4-pin EATX 12V power connector

1 x 9-pin Waterblock sensor header

2 x Water cooling thermal sensor connectors(W_in, W_out)

1 x Water_Flow rate Sensor connector

1 x Start button

1 x Reset button

1 x Safe Boot button

1 x 9-pin Monoblock integrated sensor header

1 x LN2 mode jumper

1 x MemOK! Button

2 x Aura strip header (Supports standard 12V RGB LED Strips)

1 x Front panel audio connector (AAFP)

1 x TPM connector

1 x System panel connector
