User Interface

Sprinter 150/150M/250M - 1.0.0en

Menu Setting

Menus Selections (sub-selections) Descriptions

1. Program*

Line Levelling (BIF, BF, BFFB) Select line levelling method.

)

Sighting and measurement sequence in line levelling is indicated with

highlighted 'alphabet' of the respective line levelling icons.

Cut & Fill Cut & Fill application.

2. Intermediate

Sight*

ON / OFF Enable / disable Intermediate Sight in BIF line levelling.

3. Input PtID*

Input user point ID.

4. Input BM

Input Reference Benchmark elevation.

5. Input D.ELV*

Input design elevation in Cut & Fill application.

6. Data

Manager*

View Data Viewing recorded data / deleting of a recorded data by pressing ENTER key.

Download Data (GSI / ASCII) Transferring of recorded data to PC via RS232, in GSI-8 or ASCII format.

Delete All Data Deleting of all recorded data in the on-board / internal memory.

7. Recording*

Memory Measurement recorded to on-board / internal memory.

)

In line levelling application, recording mode has to be set prior to first

backsight measurement.

Off Measurement not stored.

Ext Measurement recorded to external device in GSI-8 format via RS232 cable.

8. Adjustment

Adjustment program.

9. Inverse Staff

ON [Inverted], OFF [Upright], AUTO

[Auto recognition of staff orientation]

Recognition mode setting of staff orientation.
