Operation Messages

Sprinter 150/150M/250M - 1.0.0en

10. Operation Messages

E114 Invalid Measurement ! Make another measurement. If further measurement proved to be futile, check staff position and Inverse

Staff setting, check the lighting condition at the staff and stray light, check focusing and targeting, check

if sufficient length of barcode in the field of view.

E115 Temperature Sensor

Error !

Cover the objective telescope with a hand and switch ON the instrument. Hardware communication failed.

E116 Adjustment Error ! Carry out the adjustment with guided steps, make sure instrument is level and staff is truly vertical in

normal position. Collimation is out of correction range.

E117 BM Change Not Allowed! Exit to default measurement mode by pressing HEIGHT/DISTANCE key, and change the Benchmark

elevation in the INPUT BM menu mode.

E119 Staff Blocked Not enough barcode length for measurement.

E120 Image sensor Error! Contact services.

E121 Adjustment Inverse Staff

Not Allowed!

Check the staff orientation and staff setting.

E123 PtID Change Not Allowed Exit the message by pressing ESC key.

No. Error message Counter measure / causes

Operation message Counter measure / remark

Start Tracking! Tracking mode starts.

Stop Tracking! Tracking mode stops.

Tracking Hold! Press measure key for 3 seconds to restart tracking mode. Tracking will hold after 10 unsuccessful meas-

urements.

Abort Measurement! Current measuring process is terminated.

Downloading Data! Downloading of data from the internal memory to an external device is in progress.
