6. SPECIFICATION
Notes:
1. Given specifications may not serve the basis for claims.
2. Sven production is constantly developed. That’s why the specifications may be changed without preliminary notice.
14
OPERATION MANUAL
Output power (RMS):
subwoofer
front
center
surround
35 W
2 x 18 W
18 W
2 x 18 W
Speaker unit:
subwoofer
front tweeter
front woofer
center woofer
center tweeter
surround
6.5", 40 W
1,5", 5 W
5", 30 W
4", 15 W (8 Ohm)
1,5", 5 W
4", 20 W (full range)
Rated impedance 4 Ohm
Frequency response 20–20 000 Hz
Power supply 220 V AC, 50 Hz
Signal input port RCA jack
Separation 45 dB
S/N ratio 75 dB
Dimension:
subwoofer
front
center
surround
L 200 x D 320 x Í 400 mm
L 168 x D 220 x H 300 mm
L 400 x D 150 x H 140 mm
L 150 x D 150 x H 180 mm
Weight 7.5 + 2 x 4.1 + 3.6 + 2 x 1.8 kg

6 SPECIFICATION Output power RMS subwoofer 35 W front 2 x 18 W center 18 W surround 2 x 18 W subwoofer 6 5 40 W Speaker unit front tweeter 1 5 5 W front woofer 5 30 W center woofer 4 15 W 8 Ohm center tweeter 1 5 5 W surround 4 20 W full range Rated impedance 4 Ohm Frequency response 20 20 000 Hz Power supply 220 V AC 50 Hz Signal input port RCA jack Separation 45 dB S N ratio 75 dB Dimension Weight subwoofer L 200 x D 320 x H 400 mm front L 168 x D 220 x H 300 mm center L 400 x D 150 x H 140 mm surround L 150 x D 150 x H 180 mm 7 5 2x4 1 3 6 2x1 8 kg Notes 1 Given specifications may not serve the basis for claims 2 Sven production is constantly developed That s why the specifications may be changed without preliminary notice 14
