Rear Panel Setting
a CD Input Jack
Connect sound output of CD player with audio cable.
b AUX Input Jack
Connect appropriate sound output with audio cable.
c TV Input Jack
Connect sound output of TV set with audio cable.
d DVD Input Jack (5.1 audio input connector)
Connect the 5.1 CH sound output with sound cable.
e Front Right Speaker Output
Connect the sound output of Front Right Speaker with this jack.
f Front Left Speaker Output
Connect the sound output of Front Left Speaker with this jack.
g Centre Speaker Output
Connect the sound output of Centre Speaker with this jack.
h Right Rear Speaker Output
Connect the sound output of Right Rear Speaker with this jack.
i Left Rear Speaker Output
Connect the sound output of Left Rear Speaker with this jack.
j Power cord
k power switch
5. REMOTE CONTROL
a Standby Selector
Press ON/OFF for standby mode.
b Signal Input Selector (DVD, CD, AUX, TV)
Choose the appropriate mode according to your sound input.
c&f, l, o Centre, Surround and Subwoofer
Channels Adjustment
Press up and down to increase and decrease the
sound level.
g, i Tone Control of Bass
Press up and down to change the tone.
h, j Tone Control of Treble
Press up and down to change the tone.
k Mute Button
Turn off the volume by pressing this button.
m Virtual Surround Effect Selector
Press this button (not applicable in 5.1 CH ) to ON/
OFF the Virtual Surround.
n Bypass
Press to bypass the original sound signal.
p, q Master Volume button
Press up and down to control the volume
OPERATION MANUAL
14
Fig. 2. Rear panel
Fig. 3. Remote control
