Aircraft Status Indicators
Spark has Front LEDs and Aircraft Status Indicators. The positions of these LEDs are shown in the gure
below:
The Front LEDs show the orientation of the aircraft and the status of some functions (please refer
to the Gesture Mode “Feature Descriptions” section for more details). The Front LEDs glow solid
red when the aircraft is turned on to indicate the front or nose of the aircraft.
The Aircraft Status Indicators communicate the system status of the ight controller. Refer to the
table below for more information about the Aircraft Status Indicators.
Aircraft Status Indicator Description
Normal
Alternating red, green and yellow ashes Turning On and Self Diagnostic Testing
Alternate yellow and green ashing Warming Up
Slow green ashing P Mode with GPS
×2 Two green ashes P Mode with Vision System
Slow yellow ashing No GPS and Vision System
Fast green ashing Braking
Warning
Fast yellow ashing
Remote Controller Signal Lost
Slow red ashing Low Battery Warning
Fast red ashing Critical Low Battery Warning
Red ashing IMU Error
—
Solid Red Critical Error
Fast alternating red and yellow ashing Compass Calibration Required
Front LEDs
Aircraft Status Indicators
