2017 DJI All Rights Reserved.
11
Spark
User Manual
3D Sensing and Vision System
Spark is equipped with a 3D Sensing System
1
, consisting of a 3D infrared module at the front of the air-
craft, which scan for obstacles during ight.
The main components of the Vision System are located on the underside of the aircraft body. This in-
cludes a camera
2
and a 3D infrared module
3
. The Vision System uses 3D infrared module and image
data to help the aircraft maintain its current position, enabling precision hovering indoors or in environ-
ments where GPS signal is not available.
The 3D Sensing System constantly scan for obstacles, allowing Spark to avoid obstacles when lighting is
sufcient.
1
2
3
Detection Range
The detection range of the 3D Sensing System is depicted below. Note that the aircraft cannot sense or
avoid obstacles that are not within the detection range.
Using the Vision System
The Vision System is activated automatically when the aircraft is turned on. No further action is required.
The Vision System can be used in indoor environments where GPS is unavailable. Using the Vision
System, the aircraft can hover precisely, even without GPS.
0.2- 5 m
