Ryobi one+ cpl180mhg [10/149] English
![Ryobi one+ cpl180mhg [10/149] English](/views2/1237048/page10/bga.png)
4
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
MAINTENANCE
WARNING
Do not at any time let brake fluids, fuel,
petroleum-based products, penetrating oils etc.
Come in contact with plastic parts. They contain
chemicals that can damage, weaken or destroy
plastic.
Electric tools used on fiberglass material, wallboard,
spackling compounds or plaster are subject to
accelerated wear and possible premature failure because
the fibreglass chips and grindings are highly abrasive to
bearings, brushes, commutators etc. Consequently, we
do not recommend using this tool for extended work on
these types of materials. However, if you do work with
any of these materials, it is extremely important to clean
the tool using compressed air.
WARNING
Always wear safety goggles or safety glasses
with side shields during power tool operation or
when blowing dust. If operation is dusty, also
wear a dust mask. Failure to do so could result in
possible serious injury.
LUBRICATION
All of the bearings in this tool are lubricated with a
sufficient amount of high-grade lubricant for the life of
the unit under normal operating conditions. Therefore, no
further lubrication is required.
CLEANING THE DUST PORT AND EMPTYING
THE DUST BAG (Fig.10)
After using the planer for an extended period of time or
when planing wet or green timber, chips may build-up in
the dust port. and require cleaning. Chip build-up restricts
air flow and causes the motor to overheat.
Clean the dust port and empty the dust bag regularly.
Q Remove battery pack from tool.
WARNING
Failure to unplug your planer could result in
accidental starting causing serious injury.
Q Remove the dust bag from the dust port.
Q Clean the chip or dust build-up from the dust port of
your planer with a small piece of wood. Do not use
your hands or fingers.
Q Empty all debris from the dust bag and ensure that
the collar is free of debris.
Q Replace the dust bag.
REPLACING BLADES (Fig.11,12 & 13)
The blades in your planer are reversible. Therefore, you
can reverse the blades when one edge becomes dull.
Always replace or reverse blades in pairs. Do not attempt
to sharpen blades. If the blades become dull, replace
them.
When replacing the blades, use recommended
replacement blade only.
WARNING
Blades are sharp, use extreme caution when
replacing the blades. Failure to heed this warning
can result in serious personal injury.
Q Remove battery pack from tool.
WARNING
Failure to unplug the planer could result in
accidental starting causing serious injury.
Q Secure the planer in an upside down position.
Q Loosen the two screws securing the blade on the
blade holder using the blade wrench provided.
NOTE: Do not over-loosen the screws. If screws are
too loose, alignment of the new blade will not be
accurate.
NOTE: Before removing the old blades, take notice of
the direction of cut as well as how the tapered edge
of the old blades are oriented. The tapered edge of
the new blades must be in the same orientation as
the original blades.
Q Push the blade (to the right) out of the blade holder
using the tip of a screwdriver.
Q Remove the old blade from the blade holder.
NOTE:If the blade can not be easily pushed out of
blade holder after loosening blade securing screws,
use a block of wood to break the blade loose from
the blade holder, with a short sharp blow. Then push
the blade with a screwdriver to remove. If necessary,
tap the block of wood sharply with a small hammer to
break the blade loose.
Q Clean any sawdust or wood chips from around the
blade area.
Q Slide the new blade into the slot of the blade holder.
Q Use a screwdriver to push the blade into the blade
holder until it is centered into position.
Q Retighten the two blade securing screws using the
blade wrench.
Q Repeat the above procedure to change the other
blade.
Q Clamping screws must be tighten strongly
961067224-02(CPL-180 EU manual).indd Sec1:4 12/29/09 4:17:27 PM
