D-Link DSL-100D [3/4] Windows 98 example

D-Link DSL-100D [3/4] Windows 98 example
modem card. You will need to know the TCP/IP
properties, including the PVC values (VPI and VCI), IP
address, the gateway, and the domain server name, to
complete the configuration of the ADSL PCI modem card.
Additionally, the installation CD-ROM or diskettes of
your operating system are required for these sections.
Windows 98 (Example)
This section describes how to install the network driver
when your PC is running Windows 98. There are two
major revisions of Windows 98:
♦ Windows 98 original (henceforth referred to as the 1
st
edition)
NOTE: Before you install your
ADSL PCI modem card, determine
whether your operating system is
either Win98, 1
st
edition, or Win98, 2
nd
edition. This information is necessary
to ensure the ADSL network performs
properly as Win98, 2
nd
edition supports
advanced features which the 1
st
edition
can not. If unsure of the operating
system edition, please contact your PC
dealer for this information.
Follow these steps:
1. Confirm that you have already installed the ADSL
PCI modem in your PC and then turn on the PC.
2. Windows 98 should automatically detect the ADSL
PCI modem card and will search for a driver for the
card in the PC. The first Add New Hardware Wizard
window will appear.
3. Click “Next.”
4. Select “Search for the best driver for your device.
(Recommended).” on the second Add New Hardware
Wizard window and then click “Next.”
5. Insert the DSL-100D ADSL PCI Modem Card CD-
ROM into your CD-ROM drive and select “Specify a
location:” on the third Add New Hardware Wizard
window. Enter the correct path name (e.g.
“E:\RFC1483\Win98Com” for Windows 98 1
st
edition)
and click “Next.”
6. Windows should find the *.INF (w95dslh.inf for
Windows 98 1
st
edition) file in the directory specified
in the window above under “Location of the Driver:”
(the file name may be too long too fit in the window).
Click “Next” on the fourth Add New Hardware Wizard
window to continue.
7. Windows will start copying the drivers. The Windows
98 CD should be in your CD-ROM drive or easily
accessible.
8. The Service Options window will appear. Click
“Next” for the recommended installation (and skip to
step 11) or “Advanced” to change connection address
settings.
9. Example for RFC 1483, the default PVC values for
Ethernet over ATM are: VPI=0 and VCI=35. If
necessary, you can change these values on the window
above. The range for VPI is 0 to 255 and the range for
VCI is 0 to 65,535. Please consult your ADSL service
provider for more detailed information. Click “OK”
when you are finished modifying these settings or to
accept the default values.
NOTE: Failure to set up the correct
VPI and VCI values may cause the
ADSL network to fail.
10. Click “Next” on the Service Option window. You may
see an Insert Disk window asking you to insert the disk
labeled “Windows 98 1
st
Edition CD-ROM” into your
drive if you have not already done this. Comply with
this instruction and then click “Next.” Note that if you
3
