4
www.tapcotools.com • 800-521-7567
Parts sold in kits are not available
for purchase individually.
Item # Description
10094 ¼-20 Hex Flange Nut
12625 8'6" Moving Hinge
12626 10'6" Moving Hinge
12627 12'6" Moving Hinge
12628 14'6" Moving Hinge
12621 8'6" Base Hinge
12622 10'6" Base Hinge
12623 12'6" Base Hinge
12624 14'6" Base Hinge
10201 8'6" Back Rail
10203 10'6" Back Rail
10205 12'6" Back Rail
10207 14'6" Back Rail
10347 Left Pivot Arm
10348 Right Pivot Arm
10351 Lifting Handle Assembly
10454 8'6" Locking Handle
10458 10'6" Locking Handle
10462 12'6" Locking Handle
10464 14'6" Locking Handle
10491 8'6" Stainless Edge
10492 10'6" Stainless Edge
10493 12'6" Stainless Edge
10494 14'6" Stainless Edge
10499 8'6" Hinge Pin
10500 10'6" Hinge Pin
10501 12'6" Hinge Pin
10502 14'6" Hinge Pin
Item # Description
10504 12'6" Tape Measure
10505 10'6" Tape Measure
10506 8'6" Tape Measure
12369 14'6" Tape Measure
10511 8'6" Vinyl Strip
10512 10'6" Vinyl Strip
10513 12'6" Vinyl Strip
10514 14'6" Vinyl Strip
10519 ¼-20 x ¾" Hex Wash HD Screw
10534 3/8" Flat Washer
10535 3/8-16 Nylock Hex Nut
10538 3/8" Lock Washer
10540 Hemming Handle Assembly
10887 T-Handle Hex Key
11332 Screw ¼-20 x 7/8" Flat HD Screw
11396 Pivot Link Assembly Kit
(6) upper link 10521
(6) lower link 10381
11397 ¼" x 1 ¼" Faspin Kit
(4) Faspin 10539
11398 Hemming Handle Plug Kit
(2) Hemming Handle Plug 10531
(2) 3/8-16 2 ¼ Bolt 10536
11400 Locking Handle Pin Kit
(10) Pin 10508
(20) Keeper 10530
11408 Bolt and Nut Kit
(5) ¼-20 x 2 ½" Bolt 10503
(5) ¼-20 Nylock Nut 10520
Item # Description
11413 Hinge Clip Kit
(1) Hinge Clip 10542
(1) 10-24 ½ Phil Pan Hd Screw 10515
11416 Max Handle Plug Kit
(2) Max Lifting Handle Plugs 10209
(2) ¼-20 x 1 ½" Bolt 10518
(2) ¼-20 Nylock Nut 10520
11420 Coupling Nut Kit
(2) Coupling Nut 10349
(2) ¼-20 x ¾" Screw 10519
11531 Lifting Handle Cap
11532 Moving Hinge Cap
11533 Back Rail Cap
11534 Right Locking Handle Cap
11535 Left Locking Handle Cap (not shown)
11536 Left Base Hinge Cap
11537 Right Base Hinge Cap (not shown)
11625 3/8-16 3 ¼" Hex Cap Bolt
12042 10'/12' Max-II Parts Bag
12055 8' Max-II Parts Bag
12056 14' Max-II Parts Bag
12061 Pro 2000 C Casting
12075 8'6" Locking Anvil
12076 10'6" Locking Anvil
12077 12'6" Locking Anvil
12078 14'6" Locking Anvil
Note: For length-specic parts, 10'6"
parts numbers are shown in diagram.
