Editing and Saving a Drum Kit

In KIT menu, you can modify the parameters as you like and save to the selected user kit.

Adjusting the Volume of a Drum Kit

1. Press the [KIT] or [PAGE] button.

Select the Kit Volume page.

2. Press the [ ] or [ ] button.

Adjust the kit volume.

Switching Reverb On/Off and Setting EQ

Select the Global Reverb page and EQ pages.

2. Press the [ ] or [ ] button.

Switch Reverb ON or OFF.

Set the gain of three-band EQ (high, middle, low)

Press the [KIT] or [PAGE] button.

Selecting the Drum Instrument of the Pad

1. Press the [VOICE] button.

Select the Pad Voice page.

2. Press the [ ] or [ ] button.

Select the drum instrument of the selected pad.

Please refer to Drum Instrument List.

Adjusting the Volume, Pan and Pitch of the Pad

Setting the Pads to Play Songs

Saving the Edited Kit

Select the Pad Volume, Pad Pan, and Pad Pitch pages.

2. Press the [ ] or [ ] button.

Adjust the corresponding parameter.

Press the [VOICE] or [PAGE] button.

1. Press the [VOICE] or [PAGE] button.

Select the Pad Song and Song Number pages.

2. Press the [ ] or [ ] button.

Switch the Pad Song function ON or OFF. Select the Song

that begins playing when the following pad is struck.

The number of user kit will be flashed.

2. Press the [ ] or [ ] button.

Select a user kit to save your settings. (No. 30-45)

3. Press the [SAVE] button again.

Save the setting to the selected user kit.

Press the [SAVE] button.

HINT

If the edited kit isn’t saved before selecting

another kit, powering down the digital drum,

the changes will be lost.
