Selva MADEIRA 50 [11/46] Gruppi assemblies
![Selva MADEIRA 40 [11/46] Gruppi assemblies](/views2/1240427/page11/bgb.png)
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
81 1 7030610 Bussola su leva comando Bushing
82 1 5505060 Rondella M8 Washer M8
84 1 7025240 Distanziale su vite coppa Spacer on cup screw
85 2 4015600 Vite carter-cilindro TCEI M 8x50 Screw sump-cylinder TCEI M 8x50
86 8 4015570 Vite carter-cilindro TCEI M 8x35 Screw sump-cylinder TCEI M 8x35
87 2 5560510 Spina riferimento carter Pin
88 1 3535090 Guarnizione collettore Manifold gasket
89 2 2070140 Pacco lamellare Leaf valve
90 24 9055260 Lamella aspirazione Intake leaf
91 4 9055300 Fermo lamella Leaf retainer
93 24 4011010 Vite fermo lamella TEF M 4x8 Leaf retainer screw TEF M 4x8
95 4 4015550 Vite TCEI M6x20 Screw TCEI M6x20
96 8 4005530 Vite TE M6x20 Screw TE M6x20
98 4 5005060 Dado Nut
99 1 3560120 Anello Ring
100 1 9030250 Rasamento Shim
101 2 5550160 Spina elastica ø 4x14 Pin ø 4x14
102 2 1598805 Valvolina Valve
104 2 8055050 Raccordo a “T” "T" connector
105 1 7045050 Raccordo Connector
106 1 685030 Tubetto spia acqua Water tube
107 1 8045240 Gommino tenuta Grommet
113 1 8025090 Fascetta stringitubo Tube ring
114 2 8055041 Raccordo a L L connector
115 1 685020 Tubo Pipe
116 2 5590300 Molla fermatubo Pipe holder spring
117 1 9025452 Rondella Washer
118 2 8060455 Gommino passacavo Fairled rubber
119 1 7015460 Perno selettore Selector pin
120 1 7015265 Prigioniero Stud
121 3570450 Anello OR OR ring
122 1 7050060 Tappo Plug
123 9005250 Piastrina Plate
124 1 5505080 Rondella M6 Washer M6
125 1 5050010 Dado autobloccante M6 Selflocking nut M6
126 1 6011031 Vite azionamento pompa olio ( Tipo A ) Oil pump driving screw ( Type A )
( Versione M.A.) (M.A. version)
126 1 7025465 Distanziale ( versione senza M.A.) Spacer ( Without M.A. version)
126 1 9025275
Rasamento ( versione senza M.A.)
Shim ( Without M.A. version)
GRUPPI ASSEMBLIES
33 1 1518283
Albero motore completo Complete crankshaft
40 1 1515150 Tappo inferiore completo Complete lower crankcase head
( pos. 36+37+40+99 ) ( pos. 36+37+40+99 )
64 1 1598774 Selettore con camma C.P.S. Selector with C.P.S.cam
103 1 1581110 Tubazione recupero Pipeline
110 2 1524465 Pistone normale completo diam.80 Complete standard piston diam.80
(pos. 44+45+46+47) (pos. 44+45+46+47)
110 2 1524485 Pistone completo I magg. diam.80,20 Complete piston 1st oversize diam.80
110 2 1524505 Pistone completo II magg. diam.80,40 Complete piston 2nd oversize diam.80,20
110 2 1524525 Pistone completo III magg. diam.80,60 Complete piston 3rd oversize diam.80,40
111 2 1527230 Pacco lamellare completo Complete leaf valve
(pos. 89+90+91+92+93) (pos. 89+90+91+92+93)
