Selva MADEIRA 50 [3/46] Model madeira 40 684a madeira 50 684b madeira 40xs 684b

TECHNICAL FEATURES

MODEL MADEIRA 40 – 684A MADEIRA 50 – 684B MADEIRA 40XS – 684B

POWER 40,12 HP (29,5 Kw) 50HP (36,8 Kw) 40 ,12HP (29,5 Kw)

FULL THROTTLE (RPM) 5000/5500 5000/5500 5000/5500

DISPLACEMENT (cc.) 684 684 684

BORExSTROKE 80x68 80x68 80x68

NUMBER OF CYLINDRES 2 cyl. in line 2 cyl. in line 2 cyl. in line

ENGINE TYPE Otto cycle - 2 stroke

FUEL PUMP N°1 diaphragm pump Dellorto

CARBURETTORS

N° 2 carburettores type

Dellorto OVC 34/30

N° 2 carburettores type

Dellorto OVC 38/34

N° 2 carburettores type

Dellorto OVC 38/34

AVERAGE CONSUMPTION 14 l/h 16 l/h 15 l/h

FUEL

Unleaded gasoline- 95 R.O.N. minimum - mixed with 2 stroke outboard oil

( Only unleaded gasoline- 95 R.O.N. minimum – if engine M.A version.)

FUEL TANK separated, capacity 23 litres

ENGINE LUBRICATION 2 stroke synthetic outboard motor oil (TCW-3)

MOTOR OIL TANK Built in, capacity 2,5 liters ~ (if engine M.A version)

IGNITION marine, electronic, capacitive discharge

SPARK ADVANCE electronic, automatic programmed on engine revolution

ELECTRIC STARTING Standard with 12V/70W generator and stabiliser for battery recharge

SPARK PLUGS BOSCH W3AC-CHAMPION L 78 - HEAT RATING 275

EXHAUST underwater, vacuum operated through boss

COOLING forzed water circulation by pump

GEAR RATIO 13/27

SHIFT CONTROL mechanical:Forward-Neutral-Reverse

GEARCASE OIL API GL-5 SAE 80 W/90 MIL-L2105 C (SAE 90)

GEARCASE OIL QUANTITY 480 cc./440 gr.

PROPELLER TYP weedless 3 blades with rubber bushing

TRIM METHOD 5 changeable positions with pin (1)

SUSPENSIONS vibration dampers

TRANSOM HEIGHT standard shaft 380 mm (15 inches) long shaft 508 mm (20 inches)

WEIGHT OF STANDARD VERS.

( Kg ) abaut

(1) Idraulic power trim/tilt available on request

Selva SpA reserves the right to make changes at any time without notice in weights, material constructions and features without

incurring the obbligation to equip same on models manufactured before the date of such change
