TECHNICAL FEATURES
MODEL
Oyster 5 - F135 A Oyster 6 - F135 B
Black bass 7,5 -
F165 A
POWER
3,7 (5) 4,4 (6)
(7,5)
FULL-THROTTLE OPERATING
RANGE
5500÷6000 5500÷6000
5500÷6000
DISPLACEMENT (c.c.)
135
165
BORE x STROKE
57 x 53
63 x 53
NUMBER OF CYLINDERS
1
1
ENGINE TYPE
Otto cycle - 4 stroke OHC
FUEL PUMP
1 diaphragm pump
CARBURETOR
DELL’ORTO
FHCD 20/16 Reg.7469
DELL’ORTO
FHCD 22/18E Reg.7468
DELL’ORTO
FHCD 22/18E Reg.7470
AVERAGE CONSUMPTION 1,5 litres/hour 1,8 litres/hour 2.2 litres/hour
FUEL Unleaded gasoline
FUEL TANK
separated, capacity 12 litres
MOTOR OIL TYPE SAE 10W30 – 15W/40
IGNITION marine, electronic, capacitive discharge
SPARK ADVANCE electronic, automatic, programmed on engine revolutions
STARTING manual, rope with auto rewind on pulley (1)
SPARK PLUGS Bosch XR5 DC – NGK DPR6EA - 9
EXHAUST underwater, vacuum through boss
COOLING forzed water circulation by pump
GEAR RATIO 13/30
SHIFT CONTROLS
Forward - Neutral – Reverse
(and swivelling for 360°)
GEARCASE OIL TYPE API.GL-5 SAE 80W/90 MIL-L 2105 C (SAE 90)
GEARCASE OIL QUANTITY 220 cc./200 gr.
PROPELLER TYPE Weedless 3 blades with rubber bushing
TRIM METHOD 5 positions changeable with pin
SUSPENSIONS vibration dampers
TRANSOM HEIGHT (mm.) standard shaft 380 - long shaft 510
WEIGHT (Kg.) standard shaft 27- long shaft 27,5
(1) On request 12V/70W current generator and rectifier on polarized current tap
SELVA S.p.A. reserves the right to make changes at any time, without notice, in weights, materials, constructions and features without incurring any
obligation to equip same on models manufactured prior to date of such change.
