![Tohatsu MFS 3.5 A2 [162/165] Rapid opening of throttle causes engine to stall acceleration is not smooth](/img/pdf.png)
Tohatsu MFS 3.5 A2 [162/165] Rapid opening of throttle causes engine to stall acceleration is not smooth
![Tohatsu MFS 3.5 A2 [162/165] Rapid opening of throttle causes engine to stall acceleration is not smooth](/views2/1240886/page162/bga2.png)
9
9-9
4st 2/2.5/3.5 2007
Check operation of throttle cable.
Adjust throttle cable.
YES
YES
NO
NO
Disassemble carburetor,
and check internal components
for clogging, dirt and damage.
Any clogging,
dirt and/or damage?
Check ignition system and
compression pressure.
Clean carburetor
and/or replace
defective part(s)
with new one(s).
Is the throttle
valve tuned ?
Trouble 4 Rough acceleration.
Rapid opening of throttle causes engine to stall.
Acceleration is not smooth.
•
Inspection of Carburetor, Ignition System and Compression Pressure
