Antec One S3 [12/23] External 5 5 device installation

Press down on the drive cover tabs.

2.6 External 5.25” Device Installation

The One / One S / One S3 can support up to three 5.25” devices.

1. Remove the side panels and front bezel as directed in Section 2.2.

2. Remove the drive bay cover by pressing out on the two small tabs on either side of the cover,

then pushing the cover into the front of the bezel.

3. Replace the front bezel on the front of the chassis.

4. Slide your 5.25” drive through the front of the chassis until it lines up flush with the front bezel.

You will feel the drive lock into position.

5. If you need more clearance on the inside of the chassis for your drive, pull the drive bay tab on

the inside of the chassis toward you and push the drive in further.

Note: You can optionally secure your drive with screws for extra stability (D in Section 1.3)

Remove the drive bay cover.

Slide you drive until it locks.

Pull on the tab to adjust drive bay clearance.
