2.7 Internal 2.5” Device Installation

There are two 2.5” drive mounting locations in the One / One S / One S3: at the base of the drive cage

and a dedicated mount in the middle of the drive cage.

To install at the base of the drive cage:

1. Remove the side panels as described in Section 2.2.

2. Secure your drive with the 2.5” screws provided (D in Section 1.3). Your drive will attach at the

base of the drive cage at the bottom of the case, with screws affixing from the underside of the

case.

To install in the drive cage:

Note: The 2.5” drives install from the right side of the case.

1. Remove the side panels as described in Section 2.2.

2. Insert your device into the dedicated drive bay, with the connectors facing you.

3. You can optionally secure the drive to the cage with the 2.5” screws provided (D in Section 1.3)

Align your drive’s holes with the drive bay holes

when sliding it in.

Secure your drive with the provided 2.5” screws.
