TCX14, TCX21, TCX35 Operation

6.5 Select temperature

The status display of the temperature (fig. 3 5, page 3) indicates the selected

temperature range. With an increasing number of illuminating LEDs, the intensity of

the temperature range also increases.

Interior space temperature at approx. 25 °C ambient temperature:

➤ If you want to select the temperature to cool/heat, press the “ ” button, until

the requested temperature range is reached.

6.6 Connecting to vehicle power

6.7 Removing the lid

You can remove the lid of the cooling device (fig. 5, page 4):

➤ Open the lid until it is at a ca. 30° angle to the cooler.

➤ Pull the lid forwards and lift it off diagonally.

NOTE

The following temperature indications are subject to tolerances and are

dependent on the measuring position.

Status display Temperature range

Cooling

seven illuminating LEDs approx 0 °C in the interior space

an illuminating LED approx 16 °C in the interior space

(ECO mode)

Heating

seven illuminating LEDs approx 65 °C in the interior space

an illuminating LED approx 48 °C in the interior space

NOTE

If you connect the cooling device to the vehicle power, remember that

you may have to turn on the ignition to supply it with power.
