Texas Premium 5395TR/WA Инструкция по эксплуатации онлайн
1
Premium 5395 TR/WA
DK Betjeningsvejledning
GB User manual
Texas A/S - Knullen 22 - DK-5260 Odense S - Denmark Version 17.1
Tel. +45 6395 5555 - www.texas.dk - post@texas.dk
Содержание
- Dk betjeningsvejledning gb user manual 1
- Premium 5395 tr wa 1
- Premium_53trwa_dk_gb_17 1
- Benzinsikkerhed 5
- Betjening 5
- Dansk original brugsanvisning illustrationer ilustrations 2 symboler symbols 4 sikkerhedsforskrifter 5 identifikation af dele 6 montering 6 kabeljustering 6 betjening 7 vaskestuds 7 olieskift 7 luftfilter 7 kniv 8 tændrør 8 opbevaring og vedligeholdelse 8 reklamationsretten og generelle betingelser 8 tekniske specificationer 15 fejlsøgning 16 ce overensstemmelseserklæring dk 18 5
- Generel sikkerhed 5
- Vedligeholdelse og opbevaring 5
- Advarsel pas på at kablerne ikke kommer i klemme 6
- Bemærk kabel til choker af motor kan ikke justeres 6
- Bioklip 6
- Bortskaffelse af elektriske produkter må ikke ske sammen med almindeligt husholdningsaffald elektriske produkter skal medbringes til det lokalegenbrugscenter og bortskaffes på korrekt vis der 6
- Diverse 6
- Før maskinen tages i brug skal kabeljusteringen altid kontrolleres kablerne kontrolleres ved at koble håndtagene helt i bund og tjekke om kablet er helt stramt er kablet slapt skal det strammes kan håndtaget ikke holdes i bund uden besvær skal kablet slækkes efter første sæson må det forventes at kablerne skal justeres for optimal tilkobling da de kan strækkes ved brug følgende kabler kan være nødvendige at efterjustere 6
- Montering af fremdrift kabel illustration 4 6
- Montering af kabler rekylstarter 6
- Montering af motorstopkabel illustration 4 6
- Plæneklipperen er fremstillet i henhold til de plæneklipperen er fremstillet i henhold til de seneste sikkerhedskrav disse omfatter et knivbremsesystem der standser motor og kniv på 3 sekunder når knivbremsen aktiveres enhver sikkerhedsforanstaltning er kun effektiv når den bliver fulgt nøjagtigt følg nedenstående beskrivelse nøje når du monterer din plæneklipper 6
- Se illustration 1 6
- Styr og højdejustering illustration 2 styret kan højdejusteres så den passer bedst til din arbejdsgang før du monterer styret kan det være en god ide at have besluttet sig for hvilken arbejdshøjde bedste passer dig 6
- Udpakning illustration 2 fjern plæneklipperen fra kassen træk maskinen ud kassen indeholder 1 stk plæneklipper 1 stk opsamlerkasse 1 stk styr 6
- Vigtigt husk at fjerne bioklipprop når du bruger græsopsamleren 6
- Advarsel en kniv skal slibes så den er i 100 balance ellers kan der opstå vibrationer der kan beskadige motoren skade på motor som følge af fejl slibning er ikke dækket af garantibestemmelserne vi anbefaler derfor at lade et serviceværksted foretage slibningen 8
- Bemærk en sløv kniv kan slibes men en kniv der er slidt bøjet revnet eller på anden måde beskadiget skal udskiftes montering af kniv hvis du fjerner kniven for at slibe eller udskifte den skal du bruge en momentnøgle og nogle kraftige handsker for at beskytte dine hænder 8
- Inspektion af kniv 8
- Plæneklipperen for rengøring anbefales det at tippe forenden opad max 45 grader tipper du den til siden skal karburator og luftfilter altid vende opad da olien ellers kan løbe ud og ødelægge motoren vær opmærksom på at fjerne tændrørshætten før klipperen vedligeholdes vinteropbevaring tøm benzintanken helt og lad derefter motoren køre indtil benzinen i karburatoren er opbrugt tændrørshætten fjernes fjern tændrøret og tilsæt en teskefuld motorolie i tændrørsåbningen træk i startsnoren for at fordele olien derefter monteres tændrøret igen men ikke hætten skift olie jf afsnittet olieskift til sidst rengøres klipperen grundigt vrid en klud i olie og smør de forskellige dele for at modvirke rust 8
- Reklamationsperioden regnes fra købsdatoen og er gældende i 3 år for private i danmark 2 år i andre lande i eu maskiner solgt til erhvervsbenyttelse har 1 års garanti reklamationen dækker mangelfuld udførelse dvs fabrikationsfejl eller materiale og funktionsfejl 8
- Vedligehold løbende din plæneklipper kontroller løbende alle bolte skruer møtrikker sørg altid for at kniven er skarp det er en god idé at tage din plæneklipper til et årligt service tjek hos din autoriserede serviceforhandler se nærmeste serviceværksted på www texas dk opbevaring efter brug bør din plæneklipper opbevares i et tørt rum rengør maskinen efter hvert brug græs og snavs skal løbende fjernes fra undersiden af klippeskjoldet ved tipning af 8
- Gasoline safety 10
- Gb original instructions safety 10 identification of the parts 11 mounting 11 cable adjustment 11 operation 12 water nozzle 12 oil change 12 air filter 12 blade 13 spark plug 13 storage and maintenance 13 warranty terms and conditions 13 technical specifications 15 troubleshooting 17 ec certificate of conformity gb 18 10
- Operation 10
- Before the machine is being used the cable adjustment should always be checked the cables can be checked by activating the handles fully and check if the cable is tight if not it must be tightened if the handle cannot easily be fully activated the cable should be loosened after first season it must be expected that the cables need to be adjusted for optimal activation as cables can stretch when used the following cables may be necessary to readjust 11
- Maintenance and storage 11
- May vary from your actual model 11
- Miscellaneous 11
- Mounting the drive cable illustration 4 11
- Mounting the engine brake cable illustration 4 11
- Mounting the recoil starter 11
- Mulching plug 11
- Nb don t use the grass collector important remember to remove the mulching plug when using the grass collector 11
- See illustration id notice the illustrations may vary from your present model 11
- The lawnmower is manufactured according to the lawnmower is manufactured according to the latest safety requirements these include a blade brake that stops the motor and blade in 3 seconds when the blade brake every precaution is only effective when it is followed exactly use the following description when you mount your lawnmower 11
- Unpacking illustration 1 remove the mower from the box by pulling the machine out form the side the box contains 11
- Warning ensure that cables are not pinched handlebar and height adjustment illustration 2 the handlebars are height adjustable this means that they can be adjusted so that it best fits you before you install the handlebar it may be a good idea to have decided which height is best for you 11
- Waste electrical products must not be disposed of with the household waste this tool should be taken to your local recycling centre for safe treatment 11
- Adjusting the engine brake cable if you experience slack in engine brake cable this can be solved simply by tighten or loosen the bolt on the engine block adjusting the throttle cable if you experience slack in revolution cable this can be solved simply by tighten or loosen the bolt on the engine block 12
- Always check and refill oil before the start read and apply the instructions given in the enclosed start guide the oil level should always be between min and max on the dipstick fill with sae 30 oil there should be total 0 liter oil in the engine use only unleaded 95 octane fuel to the engine never overfill the tank cutting height adjustment illustration 3 the mower has 6 different heights the cutting height ranges from 25 mm to 80 mm start never start the mower directly on long grass recoil with primer 12
- Note for best result clean the deck with the water nozzle function right after each mowing if the grass dries out this function will not work optimally 12
- Note the blades will still rotate at up to 3 seconds after stopping 12
- Note the choke cable cannot be adjusted adjusting the drive cable if you experience slack in the drive cable this can be solved simply by tighten or loosen the bolt on the cable 12
- Oil should be changed for the first time after 2 hours then at least 1 time per year you will need an oil extractor kit art no 40 11336 oil and oil extractor kit is not included use an extractor kit and do as follows 12
- Remember to dispose the used oil so that it does no harm to nature use your local recycling station 12
- The air filter should be inspected and cleaned regularly if the filter has not been cleaned for a long time the engine s power will drop 12
- The left side of the mower deck is fitted with a water nozzle for washing the deck see illustration 1 id c 12
- Aware that removing the spark plug before the mower maintenance winter storage empty the fuel tank and let the engine run until the gasoline in the carburetor is used up spark plug removed remove the spark plug and add a teaspoon of oil engine oil in the hole pull the starter to distribute oil mount the spark plug but not the spark plug cap change oil as described in the section above finally clean the mower thoroughly dip a cloth in oil and luricate metal parts to prevent rust 13
- If you start the engine without adding oil it will be damaged and cannot be repaired and therefore not covered by the warranty 13
- Inspection of the blade 13
- Maintain your lawnmower check all bolts screws nuts and deck always make sure that the blade is sharp it s a good idea to take your lawn mower to an annual service check with your authorized service dealer see your nearest service center at www texas dk storage after use the lawnmower kept in a dry and clean room clean the machine after every use grass and dirt must be removed from the underside of the deck by tipping the mower for cleaning is recommended to tilt the front up max 45 degrees if you tilt it sideways the carburetor and air filter always face upwards since oil may run out and destroy the engine be 13
- Note a dull blade can be sharpened but a blade that is worn bent cracked or otherwise damaged must be replaced removing the blade if you remove the blade to sharpen or replace it you must use a torque wrench and some heavy gloves to protect your hands 13
- Restrictions and requirements 13
- Warning a blade must be sharpened so it is in 100 balance otherwise it may cause vibrations that could damage the engine damage to engine due to faulty sharpening is not covered by warranty we therefore recommend letting a service center sharpen the blade 13
- Wearing parts which are not covered for more than 12 months 13
- Specificationer 15
- Specifications 15
- Technical specifications 15
- Tekniske specificationer 15
- Fejlfinding_all_2017 16
- Motor vil ikke stoppe 16
- Plæneklipperen starter men kører ujævnt 16
- Startvanskeligheder 16
- Difficult to start 17
- Fejlfinding_all_2017 17
- The engine will not stop 17
- The mower starts but runs unevenly 17
- Premium_53trwa_dk_gb_17 18
