12
1. Cable for drive
2. Cable for engine brake
3. Cable for throttle cable
Note: The choke cable cannot be adjusted!
Adjusting the drive cable:
If you experience slack in the drive cable, this
can be solved simply by tighten or loosen the
bolt on the cable.
1. Tighten turning clockwise - loosen the cable.
2. Tighten turning anti clockwise - tighten the cable.
Adjusting the engine brake cable:
If you experience slack in engine brake cable,
this can be solved simply by tighten or loosen
the bolt on the engine block.
Adjusting the throttle cable:
If you experience slack in revolution cable, this
can be solved simply by tighten or loosen the
bolt on the engine block.
Operation
Always check and refill oil before the start!
Read and apply the instructions given in the
enclosed start guide!
The oil level should always be between min. and
max on the dipstick. Fill with SAE-30 oil. There
should be total 0.6 liter oil in the engine. Use
only unleaded 95 octane fuel to the engine.
Never overfill the tank.
Cutting height adjustment: Illustration 3
The mower has 6 different heights. The cutting
height ranges from 25 mm to 80 mm
Start: Never start the mower directly on long
grass.
Recoil with primer:
1. Push the primer several times, first time push 1-3
times, if necessary supplement with up to 3-5
times.
Note: It is not possible to drown engine
2. Hold the handlebar for the engine brake; this will
release the engine brake.
3. Pull the recoil starter gently until you feel
resistance in the rope, then pull quickly and
energetic. Do not at any time let go of the recoil
starter but slide it gently into starting position.
4. Hold the bar for self-propelled in order to start
mowing
Note: The blades will still rotate at up to 3
seconds after stopping.
Water nozzle
The left side of the mower deck is fitted with a
water nozzle for washing the deck. (See
Illustration 1 ID:C)
• When using the water nozzle, the machine must
be in the lowest height position and placed on the
lawn. This ensures that the water remains under
the deck during cleaning.
• Attach a hose to the nozzle.
• Turn on the water and start the engine.
• The rotations of the blades will ensure that the
water will clean the underside of the deck.
If above instruction is not followed, water may
splash back on the gearbox and clutch cable,
which increases the risk of corrosion and damage
to both parts. This will not be covered by the
warranty!
Note: For best result, clean the deck with the
water nozzle function right after each mowing. If
the grass dries out, this function will not work
optimally.
Oil change
Oil should be changed for the first time after 2
hours, then at least 1 time per year.
You will need an oil extractor kit. Art. no. 40-
11336
Oil and oil extractor kit is not included
Use an extractor kit and do as follows:
1. Turn on the engine and let it run for 5 min or until
the engine is hot. A hot engine liquefies the oil
which makes it easier to drain.
2. Suck the oil up through the oil filler hole using the
syringe that came with the oil extractor kit. Use
the hose to reach the sump.
3. Transfer the used oil into a empty container.
4. Fill the engine with SAE-30 oil.
5. Check the oil level using the dipstick. (Min / Max)
Remember to dispose the used oil so that it
does no harm to nature.Use your local
recycling station.
Air Filter
The air filter should be inspected and cleaned
regularly. If the filter has not been cleaned for a
long time, the engine’s power will drop.
1. Clean around the air filter before removing the
cap.
2. Push the two flaps down and gently pull the cover
3. Carefully remove the paper filter and inspect it.
Brush it with a soft brush. If it is very dirty,
replace it. Be careful that no dirt gets into the
inlet.
4. Wash the black foam element in the right side in
warm water and soap.
5. Press the water out of the foam element and let it
dry. Put a few drops of SAE-30 oil on the filter to
moisten it lightly. Carefully squeeze any surplus
oil out of the foam element and reattach.
6. Please note that all parts are assembled correctly
and properly closed, as shown in the picture.
