Cutting Depth

The Cutting Depth of the EDGER can be altered to one of 3

settings to a Max of approx. 38mm.

To adjust the cutting depth, loosen the Height adjustment

knob approx. 5-6 full tums, but do not remove. Push the

knob fully towards the body of the edger and at the same

time move the front wheel arm across to the opposite side of

the housing.

Raise or lower the arm to the desired position, and then pull

the height-adjusting knob

Outwards. Rotate the knob in a clockwise direction until all

of the slack is taken out of the assy. Check to ensure the

front wheel arm has located into any of the pre allocated positions and the head of the bolt

securing the front wheel arm is sitting flat on the surface of the wheel arm. Firmly tighten

the height adjustment knob.

Handle Adjustment

The tube handle can be set at three different heights.

To set the height for your comfort, slide the tube up to the level required using one of the

three holes provided and insert the coach screw. Tighten the knob fully locking the two

tubes in place.

Note: When first assembling the tube to the edger the tubes should be pulled fully up to

allow the cord to sit correctly in the tubes and motor housing.

Edging

1. Set the cut depth at 25mm and set edge guide to the down position.

2. The guard is fitted with a raised rib section which acts as a blade cut

indicator. This knob will assist in guiding the operator where the blade will

cut. During operation, the operator can sight down the rib of the guard to

where the edge is to be cut.

3. Before starting the edger, line up the tool so the edge guide rests against

the edge of the paved surface, both rear wheels should be on the paved

surface when edging.

4. HINT: When there is heavy overgrowth of grass over the paved surface it

may drag on the guard. An initial cut may be required with the edger on the

grass side. Th1s_ will require lifting up the edger guide and may require

reducing the depth of cut.

5. To avoid kickback of edger, tilt the handle down so the blade is above the

ground.

6. Turn switch on and allow blade to spin without moving the tool.

7. Slowly lift the handle to lower the blade, finding the edge of the paved

surface and start edging. Then move tool forward slowly along edge of

paved surface, keeping the edge guide pressed lightly against the

pavement edge.

8. For the first edging each season, it is best to move forward slowly because

grass is thickest then. Subsequent edging will be completed more rapidly.

9. If the tool slows down, back it up slightly until the blade returns to normal

speed. During edging some sparks may be generated from hitting stones,

this is normal. Do not attempt to edge when the grass or soil is wet or

moist -for electrical safety and to prevent clogging of the blade chamber.
