![Pioneer DEH-2210UB [22/75] The same code is displayed in the dmin and dsec areas the dtno area is blank 0ffh as it conventionally was the error mode for a vd error is 0xfb this is because the system m...](/views2/1252387/page22/bg16.png)
DEH-2200UB/XSEW5
22
1234
1234
C
D
F
A
B
E
5.2 ERROR CODE LIST
8-digit display 6-digit display 4-digit display
ERROR-xx ERR-xx E-xx
(2) LIST OF CD ERROR CODES (Error Mode: 0xFD)
Code Classification
Error code to be displayed
Details and possible causes
10
Electricity Carriage Home NG
Failure in communica-
tion with the Servo LSI
The CRG cannot move toward the inner track.
The CRG cannot move from the inner track.
--> Defective HOME SW; Failure in CRG movement; Failure in communication between
the microcomputer and the Servo LSI.
11
Electricity Focus Search NG Focusing not available
--> Disc placed upside-down; CD-RW disc used; Stains on the disc; excessive vibration.
23 Disc File Format NG Data are written in a file format not supported.
--> A CD-ROM disc on which data are written in a file format other than ISO 9660,
Level-1 or -2 (for example, in UDF) is loaded.
22 Disc No playback Playable MP3 or WMA file not found
--> No MP3 or WMA file exists on the loaded CD-ROM disc.
24
Disc All DRM All the playable files on the disc are DRM-protected.
--> This error code will not be displayed when even one file not protected by DRM is
contained on the disc.
17 Electricity Setup NG AGC protection does not work. Focus can be easily lost.
--> Scratches or stains on the disc; excessive vibration; CD-RW disc used.
15
Electricity Failure in RF data RF not read
--> A CD-R disc that does not contain data loaded
--> A CD-RW disc that does not contain data loaded
12
Electricity Spindle Lock NG
Subcode NG
RF-amp NG
Spindle not locked. Subcode not readable.
Proper RF AMP gain not obtained.
--> Defective spindle; Scratches or stains on the disc; excessive vibration.
-->
A CD-R disc that does not contain data loaded, or in a rare case, disc placed upside-down.
--> CD signal error.
30
Electricity Search Time Out Failed to reach a target address
--> CRG tracking error or scratches on the disc
50 Mechanism Failure in ejection Disc ejection not completed
--> A foreign object inserted in the mechanism; Disc jammed.
51
Mechanism Failure in retried
turning for ejection
Disc could not be ejected even after disc turning had been retried.
--> A foreign object inserted in the mechanism; Disc jammed.
52
Mechanism Failure in disc loading Disc loading not completed
--> A foreign object inserted in the mechanism; Disc jammed.
NOTES
• Indications of error codes are available only during disc operations, because CD operations are
unavailable if a mechanical error is generated.
• If the TOC cannot be read, this is not processed as an error, and operation continues accordingly.
• If you design a new head unit, be sure to use one of the display formats indicated in “Display example of
the head unit.”
ERROR CODES
(1) DISPLAY METHOD
If “0xFD” error mode is displayed in CD MODE (CD MODE area for display) or USB MODE (USB MODE area), an error code
will be displayed in the DMIN (minute display) and DSEC (second display) areas.
The same code is displayed in the DMIN and DSEC areas.
The DTNO area is blank (#0FFH), as it conventionally was.
• The error mode for a VD error is 0xFB. (This is because the system microcomputer recognizes a VD error even in the No
Display format.)
• Display example of the head unit
Depending on the display capability of LCDs, the display format varies, as shown below. XX denotes an error number.
Note: In a case of an OEM product, the error display format is subject to the specifications used by the equipment
manufacturer.
If a CD or USB memory device is inoperable, or operation of such media is stopped by an error, the error mode is established
and a cause of the error is displayed by an error code. Indication of error codes is intended to reduce the number of calls from
customers and facilitate failure analysis and repair work in servicing.
