Smart-UPS On-Line SRT8K/10K Tower/Rack-Mount 6U10
Dual Feed
System Wiring
Number
of
Phases
Voltage
Current
Full Load
(nominal)
External
Input
Circuit
Breaker
Mains
(typical)
External
Input
Circuit
Bypass
Mains
(typical)
Wire Size
Mains
(typical)
Wire Size
Bypass
(typical)
SRT8KXLI
Input 1 220/230/240 Vac 44 A 63 A / 2-pole 63 A / 2-pole 16 mm
2
or 6 AWG
16 mm
2
or 6 AWG
Input 3 380/400/415 Vac 15 A 20 A / 4-pole 63 A / 2-pole 4 mm
2
or 12 AWG
16 mm
2
or 6 AWG
Output 1 220/230/240 Vac 38 A 16 mm
2
or 6 AWG
16 mm
2
or 6 AWG
SRT10KXLI
Input 1 220/230/240 Vac 54 A 80 A / 2-pole 80 A / 2-pole 25 mm
2
or 4 AWG
25 mm
2
or 4 AWG
Input 3 380/400/415 Vac 18 A 25 A / 4-pole 80 A / 2-pole 4 mm
2
or 12 AWG
25 mm
2
or 4 AWG
Output 1 220/230/240 Vac 47 A 16 mm
2
or 6 AWG
16 mm
2
or 6 AWG
