English
5
Fatal1ty B250 Gaming K4 Series
•
1 x Ultra M.2 Socket (M2_1), supports type
2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2
PCI Express module up to Gen3 x4 (32 Gb/s)**
•
1 x M.2 Socket (M2_2), supports type 2230/2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module
up to Gen3 x2 (16 Gb/s)**
** Supports Intel® Optane
TM
Technology (M2_1 only)
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Chassis Intrusion Header
•
1 x Power LED and Speaker Header
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed
Control)
•
1 x Chassis Optional/Water Pump Fan Connector (4-pin)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power. (Smart Fan
Speed Control)
* CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector (Hi-Density Power
Connector)
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
•
1 x underbolt AIC Connector (5-pin)
•
1 x underbolt AIC Connector (10-pin)
* Only one underbolt AIC Card is supported.
•
3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 6.0 Compliant wake up events
